The MicroAce 66 is a 6” automatic dicing saw configured with a 2.4kW spindle as standard whilst other spindle sets-ups are also available to suit a variety of applications including demanding and thick substrate cutting. The MicroAce 66 can be used for a wide range of applications, not just for dicing silicon wafers. It offers a high level of configurability to get the best performance out of your application.
Come and join us at UK Semiconductors Conference 2019
Sheffield Hallam University City Campus on 10th and 11th July 2019
ABOUT LOADPOINT
Loadpoint are the pioneers of the dicing technology with expertise in creating world-leading technologies in industrial sectors such as; electronics & ICT, aerospace, medical, defence, space exploration, automotive, sensing & control.
Loadpoint develop, manufacture and supply high precision dicing machines and offer an in-house subcontract service, along with dicing consumables, service and support.
Dicing Machines
MicroAce 66
NanoAce 3200
The NanoAce 3200 is an 8” dicing saw that also finds many applications in larger area substrate cutting and dicing. The NanoAce 3200 is an automatic dicing saw with vision alignment system and high resolution closed loop linear positioning encoders in all axes where high performance tolerances are required. They offer a high level of configurability that allows the machine to be optimised to suit the application.
NanoAce 3300
The NanoAce 3300 is a 12” dicing saw that also finds many applications in larger area substrate cutting and dicing. The NanoAce 3300 is an automatic dicing saw with vision alignment system and high resolution closed loop linear positioning encoders in all axes where high performance tolerances are required. They offer a high level of configurability that allows the machine to be optimised to suit the application.
MacroAce II
MacroAce II for heavier duty applications requiring high power spindle delivery and large work areas. The MacroAce II offers a unique combination of dicing machine performance with CNC-like power and work area capability. The spindle’s drive profile has been optimised to give maximum 4KW power delivery in the 1,000 – 10,000rpm range, exactly where it is required for heavier duty ceramic & metal cutting applications. Additionally, cut depths of up to 60mm with cut lengths up to 420mm help make the MacroAce II a best-in-class leader.
Washpoint
Automatic washing and drying station.
The Washpoint is a self-contained, fully integrated free standing washing station for cleaning and drying wafers, substrates or plates up to 300mm in diameter following dicing, scribing or other machining processes.
Presspoint
Wafer mounter
A low cost solution for tape ring / hoop ring preparation and mounting. Can also be used as a simple die expander.
The Loadpoint Presspoint is one of the most versatile and efficient manual closing and post dicing stretch systems available. It requires no power and is usable straight from the box.
Dicing Consumables
Selecting the correct dicing consumables is equally as important for the dicing process. Loadpoint offer a variety of consumables to suit any customer application/process. Advice and recommendation is offered by highly experienced dicing engineers.
Dicing Blades
Loadpoint dicing blades come in a wide range to suit most dicing and cutting applications. Loadpoint blades are available in a variety of dimensions, bond types and grit sizes.
Dicing Tapes
Loadpoint offer a variety of dicing tapes sourced from leading manufactures to suit a variety of dicing applications. Tapes include but not limited to; low cost general purpose blue tape, semiconductor grade tape, UV tapes & backing tapes.
Mounting and Handling/Blade Dressing
Loadpoint offer a range of different consumables including film frames, tape rings, wafer shipers, wax, dressing materials and more.
Dicing Blade Tools
Dicing blade tools ensure flanges and blades are well maintained. These items are sold separately or collectively as a blade tool handling pack.
Here to Help
Support
Loadpoint offer an extensive range of support including training, after sales, servicing spares and global sales support contact.
Solutions
Loadpoint can provide solutions on all forms of specific dicing material requirements along with the best systems to use and help for those clients that require subcontracting services. Loadpoint offer solutions for Silicon Wafers, Photonics, Optics, Glass, MEMS, PZT & Piezo materials plus other specialist materials.
